Solving systems of linear equations via HHL using Qrisp and Catalyst¶

Intro to Qrisp¶

Since this demo is featured here, you may not have heard about Qrisp yet. If you feel addressed with this assumption, please don’t fret—we explain all the concepts necessary for you to follow along even if not already fluent in Qrisp. So, join us on this Magical Mystery Tour in the world of Qrisp, Catalyst, and HHL.

What is Qrisp? Qrisp 1 is a high-level open-source programming framework. It offers an alternative approach to circuit construction and algorithm development with its defining feature—QuantumVariables. This approach allows the user to step away from focusing on qubits and gates for circuit construction when developing algorithms, and instead allows the user to code in terms of variables and functions similarly to how one would program classically.

Qrisp also supports a modular architecture, allowing you to use, replace, and optimize code components easily. We’ll demonstrate this later in this demo.

You can install Qrisp to experiment with this implementation yourself, at your own pace, by calling pip install qrisp.

import jax
import qrisp

qv = qrisp.QuantumVariable(5)

# Apply gates to the QuantumVariable.
qrisp.h(qv[0])
qrisp.z(qv)  # Z gate applied to all qubits
qrisp.cx(qv[0], qv[3])

# Print the quantum circuit.
print(qv.qs)

QuantumCircuit:
---------------
        ┌───┐┌───┐
qv_0.0: ┤ H ├┤ Z ├──■──
        ├───┤└───┘  │
qv_0.1: ┤ Z ├───────┼──
        ├───┤       │
qv_0.2: ┤ Z ├───────┼──
        ├───┤     ┌─┴─┐
qv_0.3: ┤ Z ├─────┤ X ├
        ├───┤     └───┘
qv_0.4: ┤ Z ├──────────
        └───┘
Live QuantumVariables:
----------------------
QuantumVariable qv_0

a = qrisp.QuantumFloat(msize=3, exponent=-2, signed=False)
qrisp.h(a)
print(a)

{0.0: 0.125, 0.25: 0.125, 0.5: 0.125, 0.75: 0.125, 1.0: 0.125, 1.25: 0.125, 1.5: 0.125, 1.75: 0.125}

a = qrisp.QuantumFloat(3)
b = qrisp.QuantumFloat(3)

a[:] = 5
b[:] = 2

c = a + b
d = a - c
e = d * b
f = a / b

print(c)
print(d)
print(e)
print(f)

{7: 1.0}
{-2: 1.0}
{-4: 1.0}
{2.5: 1.0}

qb = qrisp.QuantumBool()
qrisp.h(qb)
print(qb)

{False: 0.5, True: 0.5}

qb_1 = qrisp.QuantumBool()
print(qb_1)
print(qb | qb_1)
print(qb & qb_1)

{False: 1.0}
{False: 0.5, True: 0.5}
{False: 1.0}

a = qrisp.QuantumFloat(4)
qrisp.h(a[3])
qb_3 = a >= 4
print(a)
print(qb_3)
print(qb_3.qs.statevector())

{0: 0.5, 8: 0.5}
{False: 0.5, True: 0.5}
sqrt(2)*(|0>*|False> + |8>*|True>)/2

b = qrisp.QuantumFloat(3)
b[:] = 4
comparison = a < b
print(comparison.qs.statevector())

sqrt(2)*(|0>*|False>*|4>*|True> + |8>*|True>*|4>*|False>)/2

def QPE(psi, U, precision=None, res=None):

    if res is None:
        res = qrisp.QuantumFloat(precision, -precision)

    qrisp.h(res)

    # Performs a loop with a dynamic bound in Jasp mode.
    for i in qrisp.jrange(res.size):
        with qrisp.control(res[i]):
            for j in qrisp.jrange(2**i):
                U(psi)

    return qrisp.QFT(res, inv=True)

import numpy as np


def U(psi):
    phi_1 = 0.5
    phi_2 = 0.125

    qrisp.p(phi_1 * 2 * np.pi, psi[0])  # p applies a phase gate
    qrisp.p(phi_2 * 2 * np.pi, psi[1])


psi = qrisp.QuantumFloat(2)
qrisp.h(psi)

res = QPE(psi, U, precision=3)

print(qrisp.multi_measurement([psi, res]))

{(0, 0.0): 0.25, (1, 0.5): 0.25, (2, 0.125): 0.25, (3, 0.625): 0.25}

@qrisp.terminal_sampling
def main():
    qf = qrisp.QuantumFloat(2)
    qf[:] = 3

    res = QPE(qf, U, precision=3)

    return res

main()

{0.625: 1.0}

The HHL algorithm¶

Given an $N$-by-$N$ Hermitian matrix $A$ and an $N$-dimensional vector $b$, the Quantum Linear Systems Problem (QSLP) consists of preparing a quantum state $|x\rangle$ with amplitudes proportional to the solution $x$ of the linear system of equations $Ax=b$. Thereby, it can exhibit an exponential speedup over classical methods for certain sparse matrices $A$. The HHL quantum algorithm 2 3 and, more generally, quantum linear systems algorithms, hold significant promise for accelerating computations in fields that rely heavily on solving linear systems of equations, such as solving differential equations, or accelerating machine learning.

In its eigenbasis, the matrix $A$ can be written as

where $|u_i\rangle$ is an eigenvector of $A$ corresponding to the eigenvalue $\lambda_i$.

We define the quantum states $|b\rangle$ and $|x\rangle$ as

where $|b\rangle$ and $|x\rangle$ are expressed in the eigenbasis of $A$.

Solving the linear system amounts to

You might wonder why we can’t just apply $A^{-1}$ directly to $|b\rangle$? This is because, in general, the matix $A$ is not unitary. However, we will circumnavigate this by exploiting that the Hamiltonian evolution $U=e^{itA}$ is unitary for a Hermitian matrix $A$. And this brings us to the HHL algorithm.

In theory, the HHL algorithm can be described as follows:

• Step 1: We start by preparing the state

  $$|\Psi_1\rangle = |b\rangle = \sum_i \beta_i|u_i\rangle$$

• Step 2: Applying Quantum Phase Estimation with respect to the Hamiltonian evolution $U=e^{itA}$ yields the state

  $$|\Psi_2\rangle = \sum_i \beta_i|u_i\rangle|\lambda_it/2\pi\rangle = \sum_i \beta_i|u_i\rangle|\widetilde{\lambda}_i\rangle$$

  To simplify notation, we write $\widetilde{\lambda}_i=\lambda_it/2\pi$.

• Step 3: Performing the inversion of the eigenvalues $\widetilde{\lambda}_i\rightarrow\widetilde{\lambda}_i^{-1}$ yields the state

  $$|\Psi_3\rangle = \sum_i \beta_i|u_i\rangle|\widetilde{\lambda}_i\rangle|\widetilde{\lambda}_i^{-1}\rangle$$

• Step 4: The amplitudes are multiplied by the inverse eigenvalues $\widetilde{\lambda}_i^{-1}$ to obtain the state

  $$|\Psi_4\rangle = \sum_i \lambda_i^{-1}\beta_i|u_i\rangle|\widetilde{\lambda}_i\rangle|\widetilde{\lambda}_i^{-1}\rangle$$

  This is achieved by means of a repeat-until-success procedure that applies Steps 1-3 as a subroutine. Stay tuned for more details below!

• Step 5: As a final step, we uncompute the variables $|\widetilde{\lambda}^{-1}\rangle$ and $|\widetilde{\lambda}\rangle$, and obtain the state

  $$|\Psi_5\rangle = \sum_i \lambda_i^{-1}\beta_i|u_i\rangle = |x\rangle$$

This concludes the HHL algorithm. The variable initialized in state $|b\rangle$ is now found in state $|x\rangle$. As shown in the original HHL paper, the runtime of this algorithm is $\mathcal{O}(\log(N)s^2\kappa^2/\epsilon)$ where $s$ and $\kappa$ are the sparsity and condition number of the matrix $A$, respectively, and $\epsilon$ is the precision of the solution. The logarithmic dependence on the dimension $N$ is the source of an exponential advantage over classical methods.

The HHL algorithm in Qrisp¶

Let’s put theory into practice and dive into an implementation of the HHL algorithm in Qrisp.

As a first step, we define a function that performs the inversion $\lambda\mapsto\lambda^{-1}$. In this example, we restrict ourselves to an implementation that works for values $\lambda=2^{-k}$ for $k\in\mathbb N$. (As shown above, a general inversion is available in Qrisp and will soon be updated to be compatible with QJIT compilation!)

def fake_inversion(qf, res=None):

    if res is None:
        res = qrisp.QuantumFloat(qf.size + 1)

    for i in qrisp.jrange(qf.size):
        qrisp.cx(qf[i], res[qf.size - i])

    return res

Let’s see if it works as intended.

qf = qrisp.QuantumFloat(3, -3)
qrisp.x(qf[2])
qrisp.dicke_state(qf, 1)
res = fake_inversion(qf)
print(qrisp.multi_measurement([qf, res]))

{(0.125, 8): 0.3333333333333333, (0.25, 4): 0.3333333333333333, (0.5, 2): 0.3333333333333333}

Next, we define the function HHL_encoding that performs Steps 1-4 and prepares the state $|\Psi_4\rangle$. But, how do get the values $\widetilde{\lambda}^{-1}_i$ into the amplitudes of the states, i.e. how do we go from $|\Psi_3\rangle$ to $|\Psi_4\rangle$?

Recently, efficient methods for black-box quantum state preparation that avoid arithmetic were proposed, see Bausch 4 and Sanders et al. 5. In this demo, we use a routine proposed in the latter reference which is based on a comparison between integers. This is implemented via the aforementioned comparisons for QuantumFloats.

To simplify the notation, we write $y^{(i)}=\widetilde{\lambda}^{-1}_i$. Recall that the values $y^{(i)}$ represent unsigned integers between $0$ and $2^n-1$.

Starting from the state

we prepare a uniform superposition of $2^n$ states in a case_indicator QuantumFloat.

Next, we calculate the comparison $a\geq b$ between the res and the case_indicator into a QuantumBool qbl.

Finally, the case_indicator is unprepared with $n$ Hadamards and we obtain the state

where $|\Phi\rangle$ is an orthogonal state with the last variables not in $|0\rangle_{\text{case}}|0\rangle_{\text{qbl}}$. Hence, upon measuring the case_indicator in state $|0\rangle$ and the target qbl in state $|0\rangle$, the desired state is prepared.

Steps 1-4 are performed as a repeat-until-success (RUS) routine. This decorator converts the function to be executed within a RUS procedure. The function must return a Boolean value as first return value and is repeatedly executed until the first return value is True.

@qrisp.RUS(static_argnums=[0, 1])
def HHL_encoding(b, hamiltonian_evolution, n, precision):

    # Prepare the state |b>. Step 1
    qf = qrisp.QuantumFloat(n)
    # Reverse the endianness for compatibility with Hamiltonian simulation.
    qrisp.prepare(qf, b, reversed=True)

    qpe_res = QPE(qf, hamiltonian_evolution, precision=precision)  # Step 2
    inv_res = fake_inversion(qpe_res)  # Step 3

    case_indicator = qrisp.QuantumFloat(inv_res.size)

    with qrisp.conjugate(qrisp.h)(case_indicator):
        qbl = (case_indicator >= inv_res)

    cancellation_bool = (qrisp.measure(case_indicator) == 0) & (qrisp.measure(qbl) == 0)

    # The first return value is a boolean value. Additional return values are QuantumVariables.
    return cancellation_bool, qf, qpe_res, inv_res

The probability of success could be further increased by oblivious amplitude amplification to achieve optimal asymptotic scaling.

Finally, we put all things together into the HHL function.

This function takes the follwoing arguments:

• b: The vector $b$.

• hamiltonian_evolution: A function performing hamiltonian_evolution $e^{itA}$.

• n: The number of qubits encoding the state $|b\rangle$ ($N=2^n$).

• precision: The precision of the quantum phase estimation.

The HHL function uses the previously defined subroutine to prepare the state $|\Psi_4\rangle$ and subsequently uncomputes the $|\widetilde{\lambda}\rangle$ and $|\lambda\rangle$ quantum variables leaving the first variable, that was initialized in state $|b\rangle$, in the target state $|x\rangle$.

def HHL(b, hamiltonian_evolution, n, precision):

    qf, qpe_res, inv_res = HHL_encoding(b, hamiltonian_evolution, n, precision)

    # Uncompute qpe_res and inv_res
    with qrisp.invert():
        QPE(qf, hamiltonian_evolution, res=qpe_res)
        fake_inversion(qpe_res, res=inv_res)

    # Reverse the endianness for compatibility with Hamiltonian simulation.
    for i in qrisp.jrange(qf.size // 2):
        qrisp.swap(qf[i], qf[n - i - 1])

    return qf

from qrisp.operators import QubitOperator
import numpy as np

A = np.array([[3 / 8, 1 / 8], [1 / 8, 3 / 8]])
b = np.array([1, 1])

H = QubitOperator.from_matrix(A).to_pauli()


# By default e^{-itH} is performed. Therefore, we set t=-pi.
def U(qf):
    H.trotterization()(qf, t=-np.pi, steps=1)

@qrisp.terminal_sampling
def main():
    x = HHL(tuple(b), U, 1, 3)
    return x


res_dict = main()

for k, v in res_dict.items():
    res_dict[k] = v**0.5

print(res_dict)

{0.0: 0.7071067811865476, 1.0: 0.7071067811865476}

x = (np.linalg.inv(A) @ b) / np.linalg.norm(np.linalg.inv(A) @ b)
print(x)

[0.70710678 0.70710678]

def hermitian_matrix_with_power_of_2_eigenvalues(n):
    # Generate eigenvalues as inverse powers of 2.
    eigenvalues = 1 / np.exp2(np.random.randint(1, 4, size=n))

    # Generate a random unitary matrix.
    Q, _ = np.linalg.qr(np.random.randn(n, n))

    # Construct the Hermitian matrix.
    A = Q @ np.diag(eigenvalues) @ Q.conj().T

    return A


# Example
n = 3
A = hermitian_matrix_with_power_of_2_eigenvalues(2**n)

H = QubitOperator.from_matrix(A).to_pauli()


def U(qf):
    H.trotterization()(qf, t=-np.pi, steps=5)


b = np.random.randint(0, 2, size=2**n)

print("Hermitian matrix A:")
print(A)

print("Eigenvalues:")
print(np.linalg.eigvals(A))

print("b:")
print(b)

Hermitian matrix A:
[[ 0.19252221  0.03518761 -0.08725666  0.02288045  0.04538538  0.03247052
  -0.06519315 -0.06229545]
 [ 0.03518761  0.28758984  0.03595881  0.06702119  0.03489919  0.07145221
   0.07085617 -0.10555209]
 [-0.08725666  0.03595881  0.28859598  0.00165777 -0.05503796 -0.03801707
   0.13179087  0.03443008]
 [ 0.02288045  0.06702119  0.00165777  0.26810863 -0.12651043  0.00385685
  -0.01492278 -0.10505962]
 [ 0.04538538  0.03489919 -0.05503796 -0.12651043  0.34469893  0.07605711
   0.01253655  0.02660667]
 [ 0.03247052  0.07145221 -0.03801707  0.00385685  0.07605711  0.31567327
   0.080171   -0.01770181]
 [-0.06519315  0.07085617  0.13179087 -0.01492278  0.01253655  0.080171
   0.30119828  0.03446737]
 [-0.06229545 -0.10555209  0.03443008 -0.10505962  0.02660667 -0.01770181
   0.03446737  0.25161286]]
Eigenvalues:
[0.25  0.5   0.5   0.125 0.125 0.5   0.125 0.125]
b:
[1 0 0 0 0 0 0 1]

@qrisp.terminal_sampling
def main():
    x = HHL(tuple(b), U, n, 4)
    return x


res_dict = main()

for k, v in res_dict.items():
    res_dict[k] = v**0.5

np.array([res_dict[key] for key in sorted(res_dict)])

array([0.73688311, 0.11916253, 0.09056467, 0.11650071, 0.09336856,
       0.04641304, 0.04607175, 0.63877596])

x = (np.linalg.inv(A) @ b) / np.linalg.norm(np.linalg.inv(A) @ b)
print(x)

[ 0.73761732  0.11838953  0.08853343  0.11632373 -0.09299411 -0.04581715
  0.04179596  0.63878104]

QJIT compilation with Catalyst¶

The solution that we saw so far only ran within the Python-based Qrisp internal simulator, which doesn’t have to care about silly things such as coherence time. Unfortunately, this is not (yet) the case for real quantum hardware so it is of paramount importance that the classical real-time computations (such as the while loop within the repeat-until-success steps) are executed as fast as possible. For this reason the QIR specification was created.

QIR essentially embeds quantum aspects into LLVM, which is the foundation of a lot of modern compiler infrastructure. This implies QIR based software stacks are able to integrate a large part of established classical software and also express real-time control structures. Read more about QIR at the QIR Alliance website and the Advancing hybrid quantum–classical computation with real-time execution paper.

Jasp has been built with a direct Catalyst integration implying Jasp programs can be converted to QIR via the Catalyst pipeline. This conversion is straightforward: You simply capture the Qrisp computation using the make_jaspr function and then call to_qir.

def main():
    x = HHL(tuple(b), U, n, 4)
    # Note that we have to return a classical value
    # (in this case the measurement result of the
    # quantum variable returned by the HHL algorithm)
    # Within the above examples, we used the terminal_sampling
    # decorator, which is a convenience feature and allows
    # a much faster sampling procedure.
    # The terminal_sampling decorator expects a function returning
    # quantum variables, while most other evaluation modes require
    # classical return values.
    return qrisp.measure(x)


jaspr = qrisp.make_jaspr(main)()
qir_str = jaspr.to_qir()
# Print only the first few lines - the whole string is very long.
print(qir_str[:2000])

; ModuleID = 'LLVMDialectModule'
source_filename = "LLVMDialectModule"
target datalayout = "e-m:e-p270:32:32-p271:32:32-p272:64:64-i64:64-i128:128-f80:128-n8:16:32:64-S128"
target triple = "x86_64-unknown-linux-gnu"

@"{'shots': 0, 'mcmc': False, 'num_burnin': 0, 'kernel_name': None}" = internal constant [66 x i8] c"{'shots': 0, 'mcmc': False, 'num_burnin': 0, 'kernel_name': None}\00"
@LightningSimulator = internal constant [19 x i8] c"LightningSimulator\00"
@"/home/positr0nium/miniforge3/envs/qrisp/lib/python3.10/site-packages/pennylane_lightning/liblightning_qubit_catalyst.so" = internal constant [120 x i8] c"/home/positr0nium/miniforge3/envs/qrisp/lib/python3.10/site-packages/pennylane_lightning/liblightning_qubit_catalyst.so\00"
@__constant_xi64_3 = private constant i64 -4
@__constant_1024xi64 = private constant [1024 x i64] zeroinitializer
@__constant_xi1 = private constant i1 false
@__constant_xi64_2 = private constant i64 4
@__constant_xi64_1 = private constant i64 3
@__constant_xi64_0 = private constant i64 30
@__constant_30xi64 = private constant [30 x i64] [i64 30, i64 29, i64 28, i64 27, i64 26, i64 25, i64 24, i64 23, i64 22, i64 21, i64 20, i64 19, i64 18, i64 17, i64 16, i64 15, i64 14, i64 13, i64 12, i64 11, i64 10, i64 9, i64 8, i64 7, i64 6, i64 5, i64 4, i64 3, i64 2, i64 1]
@__constant_xf64_34 = private constant double 0xBF919CF5D85DB47A
@__constant_xf64_33 = private constant double 0xBF89C4C2643A2DEA
@__constant_xf64_32 = private constant double 0xBF8696E980F4B09E
@__constant_xf64_31 = private constant double 0x3F69A6304F46D56B
@__constant_xf64_30 = private constant double 0xBF97F300BE6AA82E
@__constant_xf64_29 = private constant double 0x3F75120CFFA6C0C9
@__constant_xf64_28 = private constant double 0x3FA0EEDA934AC632
@__constant_xf64_27 = private constant double 0x3F9B793155FE33E5
@__constant_xf64_26 = private constant double 0x3EFEF5A8835D9B8E
@__constant_xf64_25 = private constant double 0xBF826D7D6D20BB88
@__constant_xf64_24 = private const

The Catalyst runtime¶

Jasp is also capable of targeting the Catalyst execution runtime (i.e., the Lightning simulator). There are, however, still some simulator features to be implemented on Jasp side, which prevents efficient sampling. We restrict the demonstration to the smaller examples from above to limit the overall execution time required. (Warning: The execution may take more than 15 minutes.)

A = np.array([[3 / 8, 1 / 8], [1 / 8, 3 / 8]])

b = np.array([1, 1])

H = QubitOperator.from_matrix(A).to_pauli()


# By default e^{-itH} is performed. Therefore, we set t=-pi.
def U(qf):
    H.trotterization()(qf, t=-np.pi, steps=1)


@qrisp.qjit
def main():
    x = HHL(tuple(b), U, 1, 3)

    return qrisp.measure(x)


samples = []
for i in range(5):
    samples.append(float(main()))

print(samples)

[1.0, 1.0, 0.0, 1.0, 0.0]

Scrolling back to the terminal_sampling cell, we see that the expected distribution is 50/50 between one and zero, which roughly agrees to the result of the previous cell and concludes this demo.

Conclusion¶

In this demo, we have shown how to implement the HHL algorithm featuring classical real-time computations in the high-level language Qrisp. This algorithm is important in a variety of use cases such as solving differential equations, accelerating machine learning, and more generally, any task that involves solving linear systems of equations. Along the way, we have dipped into advanced concepts such as Linear Combination of Unitaries and Hamiltonian simulation. Moreover, we have demonstrated how Qrisp and Catalyst complement each other for translating a high-level implementation into low-level QIR.

References¶

1

R. Seidel, S. Bock, R. Zander, M. Petrič, N. Steinmann, N. Tcholtchev, M. Hauswirth, “Qrisp: A Framework for Compilable High-Level Programming of Gate-Based Quantum Computers”, arXiv:2406.14792, 2024.

2

A. W. Harrow, A. Hassidim, S. Lloyd, “Quantum Algorithm for Linear Systems of Equations”, Physical Review Letters 103(15), 150503, 2009.

3

A. Zaman, H. J. Morrell, H. Y. Wong, “A Step-by-Step HHL Algorithm Walkthrough to Enhance Understanding of Critical Quantum Computing Concepts”, IEEE Access 11, 2023.

4

J. Bausch, “Fast Black-Box Quantum State Preparation”, Quantum 6, 773, 2022.

5

Y. R. Sanders, G. H. Low, A. Scherer, D. W. Berry, “Black-Box Quantum State Preparation without Arithmetic”, Physical review letters 122(2), 020502, 2019.

About the authors¶
