How to use Catalyst with Lightning-GPU

Published: February 21, 2025. Last updated: February 21, 2025.

We have been sharing details about how to use Catalyst, our quantum just-in-time (QJIT) compiler framework, to optimize and compile hybrid quantum-classical programs with different PennyLane devices. Here, we will demonstrate how to leverage the power of Lightning-GPU to accelerate your quantum simulations.

Lightning-GPU is our high-performance CUDA-backed state-vector simulator for PennyLane. This device enables fast quantum circuit simulations on NVIDIA GPUs and has been recently integrated with Catalyst.

How to use Catalyst with Lightning-GPU

Let’s get started with setting up the environment and running a simple example to highlight Catalyst with Lightning-GPU features.

Setting up your environment

Using Lightning-GPU is particularly beneficial when dealing with large quantum circuits or when running simulations that require significant computational resources. By offloading the heavy linear algebra operations to GPUs, we can achieve substantial performance improvements.

Lightning-GPU can be used on systems equipped with NVIDIA GPUs of generation SM 7.0 (Volta) and greater, specifically, it is optimized for Linux X86-64 or ARM64 machines with CUDA-12 installed.

To use Catalyst with Lightning-GPU, you need to install PennyLane, the qjit() compiler framework, and the Lightning-GPU plugin (lightning.gpu). These packages can be installed from the Python Package Index (PyPI) using the following command:

pip install pennylane pennylane-catalyst pennylane-lightning-gpu

If you are using a different hardware configuration or operating system, you may need to install these packages from source. Detailed instructions for source installation can be found in the respective documentation of each package.

Compile and run a circuit

Here, we use a simple PennyLane circuit to demonstrate how to compile and run a quantum program on Lightning-GPU with Catalyst.

First, we create a lightning.gpu device with 28 qubits using the device() function. We then define a quantum circuit that applies layers of RZ() and RY() rotations to each wire and returns the expectation value as the measurement result.

To compile the circuit with Catalyst, we use the qjit() decorator. The autograph=True compilation option compiles the circuit with for-loops. This allows Catalyst to efficiently capture control-flow operations, reduce the compilation time, and generate a more efficient program.

import pennylane as qml
import jax.numpy as jnp

import jax

# Set number of wires num_wires = 28

# Set a random seed key = jax.random.PRNGKey(0)

dev = qml.device("lightning.gpu", wires=num_wires)

@qml.qjit(autograph=True) @qml.qnode(dev) def circuit(params):

# Apply layers of RZ and RY rotations for i in range(num_wires): qml.RZ(params[3*i], wires=[i]) qml.RY(params[3*i+1], wires=[i]) qml.RZ(params[3*i+2], wires=[i])

return qml.expval(qml.PauliZ(0) + qml.PauliZ(num_wires-1))

# Initialize the weights weights = jax.random.uniform(key, shape=(3 * num_wires,), dtype=jnp.float32)

>>> circuit(weights)
1.7712995142661776

Lightning-GPU has feature parity with the rest of Lightning state-vector simulators, providing native support for many PennyLane’s operations and measurement processes with a fast adjoint-Jacobian differentiation implementation.

In the next section, we demonstrate how to compute the gradient of your quantum programs using the native adjoint-Jacobian method on this device.

Compute gradients

We use grad() to compute the gradient of the circuit with respect to a set of trainable arguments. This method is particularly useful for variational quantum algorithms where the gradient of the cost function with respect to the circuit parameters is required. You can check out this demo for more information on compiling and optimizing Variational Quantum Eigensolver (VQE) with Catalyst.

@qml.qjit(autograph=True)
def workflow(params):
    g = qml.grad(circuit)
    return g(params)

>>> workflow(weights)
[ 8.8817842e-16 ... -6.2915415e-01  0.0000000e+00]

Note that in the above example, we didn’t use method="adjoint". The adjoint-Jacobian is the default gradient method when you compile and run your program on Lightning-GPU.

Optimize parameters

Now that we have seen how to leverage the device differentiation capabilities, we can move on to further optimizing the circuit parameters using Catalyst. We follow the same steps as in the VQE demo, to QJIT-compile the entire optimization workflow.

import catalyst
import optax

opt = optax.sgd(learning_rate=0.4)

def update_step(i, params, opt_state): energy, grads = catalyst.value_and_grad(circuit)(params) updates, opt_state = opt.update(grads, opt_state) params = optax.apply_updates(params, updates) catalyst.debug.print("Step = {i}", i=i) return (params, opt_state)

@qml.qjit def optimization(params): opt_state = opt.init(params) (params, opt_state) = qml.for_loop(0, 10, 1)(update_step)(params, opt_state) return params

>>> optimization(weights)
Step = 0
Step = 1
Step = 2
Step = 3
Step = 4
Step = 5
Step = 6
Step = 7
Step = 8
Step = 9
[1.24479175e-01 ... 9.45755959e-01 4.64060426e-01]

We used Optax, a library designed for optimization using JAX, as well as the QJIT-compatible for_loop() function to compile the entire optimization loop, leading to further performance improvements.

Précis

In this tutorial, we have shown how to use Catalyst with Lightning-GPU to accelerate quantum simulations on NVIDIA GPUs. We have compiled a simple quantum circuit with Catalyst, computed the gradient of the circuit using the adjoint-Jacobian method, and optimized the circuit parameters using Catalyst and Optax.

To learn more about all the integrated devices, check out the Catalyst Devices guide.
